Tag : Identifcation;Container / trailer

128 Kbyte SaviTag 410-108

Plastic mounting bracket for each ordered Tag

MANUFACTURER: SAVI TECHNOLOGY

MANUFACTURER’S MODEL: ST-410-108

DESCRIPTION

INCLUDES

128 Kbyte SaviTag 410

Plastic mounting bracket for each ordered Tag

SPECIFICATIONS

Physical

Dimensions: 8.75" x 2.8" x 1.38"

Weight: 7 oz

Environmental

Temperature (Operating): -32C to +70C

Temperature (Storage): -40C to +70C

Humidity: 100% non-condensing

Vibration: MIL-Std-810E Method 514.4, Category 10

RF Frequency: 433.92MHz (transmit and receive)

Range (unobstructed): 600 ft

Transmission Power: 0.025mW average EIRP

Modulation: FSK; 100kHz (peak-to-peak)

Receiver Sensitivity: -98dBm

Type: Superheterodyne

IF Frequency: 10.7MHz

IF Bandwidth: 450kHz

Approval: Unlicensed operation under FCC Part 15.231

Data Rate: 28 Kbps

Power

Battery Type: 3.6V primary lithium, 2.5Ah, replaceable by user

Battery Life: 4 years at 2 collections per day
